Toyota Echo I (1999-2005) w/o tachometer right front turn signal light turn park w/ tachometer Wiring diagram

+B EHW BG (ON LEFT "C" PILLAR) BI (ON CENTER REAR OF LUGGAGE COMPT) BLK WIRE COMBINATION METER COMBINATION SWITCH DOOR LOCKS SYSTEM EA (ON REAR OF RIGHT FRONT FENDER) EC (ON REAR OF LEFT FRONT FENDER) ER IG FLASHER RELAY GAUGE FUSE GRN WIRE GRN/BLK WIRE HAZ FUSE HAZARD SWITCH (CENTER CLUSTER SWITCH) HEAD HIGH MOUNTED STOP LIGHT (W/ BULB TYPE) RIGHT REAR SIDE MARKER LIGHT HIGH MOUNTED STOP LIGHT (W/ LED TYPE) HOT AT ALL TIMES HOT IN ON OR START ID (AT LEFT KICK PANEL) IF (AT RIGHT KICK PANEL) INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH, NEAR BASE OF ``A" PILLAR) JUNCTION CONNECTOR 15 (REARWARD OF LEFT REAR FENDERWELL) JUNCTION CONNECTOR 5 (BEHIND LEFT KICK PANEL) JUNCTION CONNECTOR 9 LEFT FRONT TURN SIGNAL LIGHT TURN LEFT LICENSE PLATE LIGHT LEFT REAR SIDE MARKER LIGHT LEFT REAR COMBINATION LIGHT LEFT RIGHT LIGHT CONTROL SWITCH LR LL OFF TAIL ORG/ WIRE PARK RED WIRE RIGHT LICENSE PLATE LIGHT RIGHT REAR COMBINATION LIGHT STOP STOP FUSE STOPLIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) TAIL TAIL FUSE TAILLIGHT RELAY (BEHIND LEFT SIDE OF DASH, NEXT TO INSTRUMENT PANEL J/B) TURN TURN SIGNAL INDICATOR LIGHTS TURN SIGNAL SWITCH TURN STOP TAIL W/ WIRELESS DOOR LOCK W/ WIRELESS DOOR LOCKS W/O TACHOMETER RIGHT FRONT TURN SIGNAL LIGHT TURN PARK W/ TACHOMETER W/O WIRELESS DOOR LOCKS WHT WIRE WHT/BLK WIRE YEL WIRE
