Toyota Echo I (1999-2005) w/ keyless entry/ foglight w/o keyless entry/ foglight Wiring diagram
This page shows the only wiring diagram for the component.w/ keyless entry/ foglight w/o keyless entry/ foglight, which is found in the car Toyota Echo I (1999-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ keyless entry/ foglight w/o keyless entry/ foglight (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 DRL
BEAM IND
BLK WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLU WIRE
BLU/YEL WIRE
BRAKE FLUID LEVEL WARNING SWITCH (ON BRAKE FLUID RESERVOIR)
BRAKE IND
BRN WIRE
COMB- INATION METER
COMBINATION SWITCH
DIMMER SWITCH
DOME FUSE
DOOR LOCK CONTROL RELAY (NEAR INSTRUMENT CLUSTER)
EA (ON REAR OF RIGHT FRONT FENDER)
EC (ON REAR OF LEFT FRONT FENDER)
ECU-B FUSE
ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT)
FOG
FOG FUSE
FOGLIGHT RELAY (NEXT TO INSTRUMENT PANEL J/B)
FOGLIGHT SWITCH
GAUGE FUSE
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
HEAD OFF TAIL LIGHT CONTROL SWITCH
HEADLIGHT RELAY (W/ KEYLESS ENTRY) (NEXT TO INSTRUMENT PANEL J/B)
HI CHG BRK PKB IG
HOT AT ALL TIMES
HOT IN ON OR START
ID (AT LEFT KICK PANEL)
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH, NEAR BASE OF ``A" PILLAR)
J/C 12
J/C 5 (BEHIND LEFT KICK PANEL)
J/C 6, 7 (BELOW INSTRUMENT CLUSTER)
LEFT FRONT FOG LIGHT
LEFT H-LP FUSE
LEFT HEADLIGHT
ORG/ WIRE
PARKING BRAKE SWITCH (ON BASE OF PARK BRAKE LEVER)
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT FOG LIGHT
RIGHT H-LP FUSE
RIGHT HEADLIGHT
STARTING/ CHARGING SYSTEM
W/ KEYLESS ENTRY/ FOGLIGHT
W/ KEYLESS ENTRY/ FOGLIGHT W/O KEYLESS ENTRY/ FOGLIGHT
W/ TACHOMETER W/O TACHOMETER EA (ON REAR OF RIGHT FRONT FENDER)
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Headlights circuit, with drl -> W/ KEYLESS ENTRY/ FOGLIGHT W/O KEYLESS ENTRY/ FOGLIGHT
