Toyota Echo I (1999-2005) right rear door courtesy switch Wiring diagram

1 2 3 4 5 GND RDA PRG 4 DOOR BLK/RED WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/YEL WIRE BRN/WHT WIRE BRN/YEL WIRE COMBINATION METER D/L FUSE DETECT DOME FUSE DOOR LOCK CONTROL SWITCH (W/O POWER WINDOWS) ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT) FENDERWELL) GAUGE FUSE GRN/BLK WIRE GRN/WHT WIRE GRY WIRE HORNS SYSTEM EXTERIOR LIGHTS SYSTEM HEADLIGHTS SYSTEM HOT AT ALL TIMES HOT IN ON OR START ID (AT LEFT KICK PANEL) INSTRUMENT CLUSTER INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH, NEAR BASE OF ``A" PILLAR) J/C 12 J/C 13, 14 J/C 5 (BEHIND LEFT KICK PANEL) JUNCTION CONNECTOR 10 (REARWARD OF LEFT REAR JUNCTION CONNECTOR 6, 7 (BEHIND UPPER CENTER OF DASH, BELOW LEFT DOOR LOCK CONTROL SWITCH LEFT FRONT DOOR COURTESY SWITCH LEFT REAR DOOR COURTESY SWITCH LOCK ORG/ BLU WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE RIGHT DOOR LOCK CONTROL SWITCH (W/ POWER WINDOWS) RIGHT FRONT DOOR COURTESY SWITCH RIGHT REAR DOOR COURTESY SWITCH RIGHT REAR DOOR LOCK MOTOR (4 DOOR) UNLK UNLOCK WARNING SWITCH WHT/BLK WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE
