Toyota Echo I (1999-2005) rdi fuse htr Wiring diagram
This page shows the only wiring diagram for the component.rdi fuse htr, which is found in the car Toyota Echo I (1999-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rdi fuse htr (1 of 1)
A/C FUSE
A/C MG RELAY, A/C TRIPLE PRESSURE SWITCH
ABS ACTUATOR WITH ECU
ABS FUSE
ALT FUSE
BATTERY
BLK WIRE
BLOWER MOTOR RESISTOR
BLU WIRE
D/L FUSE HAZ FUSE
DATA LINK CONNECTOR 3
DEF FUSE
DOME FUSE EFI FUSE
DOOR LOCK CONTROL RELAY THEFT DETERRENT ECU
DRL RELAY (MAIN)
ECU-B FUSE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
FAN 1 RELAY RELAY
FLASHER RELAY
FOG FUSE
FOG LIGHT RELAY
FUSE
FUSIBLE LINK BLOCK (LEFT SIDE OF ENGINE COMPT)
GENERATOR
GRN WIRE
HEATER RELAY
HORN FUSE
HORN RELAY, THEFT DETERRENT ECU
HTR FUSE
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH, NEAR BASE OF ``A" PILLAR)
LEFT HEADLIGHT, DRL 5 RELAY
LH H-LP FUSE
MAIN FUSE
NCA WIRE
OBD FUSE
ORG/ WIRE
POWER FUSE
POWER RELAY
RDI FUSE HTR
REAR WINDOW DEFOGGER RELAY
RED WIRE
RH H-LP FUSE
RIGHT HEADLIGHT, HEADLIGHT RELAY
ST FUSE
ST RELAY
STOP FUSE
STOP LIGHT SWITCH
TAIL FUSE
TAILLIGHT RELAY, COMBINATION SWITCH
TO IGNITION SWITCH (DIAGRAM 2 OF 2)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 2) -> RDI FUSE HTR
