Toyota Echo I (1999-2005) pnk vupr Wiring diagram
This page shows the only wiring diagram for the component.pnk vupr, which is found in the car Toyota Echo I (1999-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk vupr (1 of 1)
+SR P+ P- SIL D- D+ +SL
1 2 3 4 5 6 7 8 9 10 11 12 PL- PL+ DML- DML+ SFL+ SFL- VUPL
1 2 3 4 5 6 7 8 9 10 11 12 SFR- SFR+ DMR+ DMR- PR+ PR- ESR RBE+ FSR SSR+
1 2 DMR- DMR+
2 1 DML+ DML-
4 3 2 1 ESL FSL SSL+ VUPL
BLK WIRE
BLK/BLU WIRE
BLK/ORG (OR LT BLU) WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT (OR LT BLU) WIRE
BLK/YEL (OR WHT) WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN (OR LT BLU) WIRE
BRN/WHT (OR LT BLU) WIRE
CENTER AIR BAG SENSOR ASSEMBLY (BEHIND LOWER CENTER OF DASH)
ESR
FSR SSR+ VUPR
GAUGE FUSE
GRN WIRE
GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION SWITCH
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH, NEAR BASE OF ``A" PILLAR)
J/C 10 (REARWARD OF LEFT REAR FENDERWELL)
J/C 15 (REARWARD OF LEFT REAR FENDERWELL)
LEFT BUCKLE SWITCH (IN LEFT FRONT SEAT BELT BUCKLE)
LEFT PRETENSIONER (NEAR BOTTOM OF LEFT "B" PILLAR)
LEFT SIDE AIR BAG SENSOR (W/SIDE AIR BAG) (AT BASE OF LEFT "B" PILLAR)
LEFT SIDE AIR BAG SQUIB (W/SIDE AIR BAG)
LOCK
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT PNK WIRE
PNK VUPR WIRE
PNK/BLK (OR WHT) WIRE
PNK/BLU WIRE
RED WIRE
RED/BLK WIRE
RIGHT BUCKLE SWITCH (IN RIGHT FRONT SEAT BELT BUCKLE)
RIGHT SIDE AIR BAG SQUIB (W/SIDE AIR BAG)
SL-
SSL+ FSL LBE+ ESL
TC -SR
WHT (OR LT BLU) WIRE
WHT WIRE
WHT/BLK (OR LT BLU) WIRE
WHT/GRN WIRE
WHT/RED (OR LT BLU) WIRE
WHT/RED WIRE
YEL (OR LT BLU) WIRE
YEL WIRE
YEL/BLK (OR LT BLU) WIRE
YEL/BLK WIRE
YEL/GRN (OR LT BLU) WIRE
YEL/GRN WIRE
YEL/RED (OR LT BLU) WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit (1 of 2) -> PNK VUPR WIRE
