Toyota Echo I (1999-2005) combination switch comb- ination meter 17 2 Wiring diagram
This page shows the only wiring diagram for the component.combination switch comb- ination meter 17 2, which is found in the car Toyota Echo I (1999-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram combination switch comb- ination meter 17 2 (1 of 1)
BLK WIRE
BLU WIRE
COMBINATION SWITCH COMB- INATION METER 17 2
EA (ON REAR OF RIGHT FRONT FENDER)
FRONT WIPER MOTOR (ON CENTER OF FIREWALL, AT BASE OF WINDSHIELD)
FRONT WIPER SWITCH
GRN WIRE
GRY WIRE
HIGH OFF
HOT IN ON OR START
ID (AT LEFT KICK PANEL)
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH, NEAR BASE OF ``A" PILLAR)
LOW/ MIST INT
LOW/ MIST INT INT LOW/ MIST
OFF
RED WIRE
RED/BLK WIRE
SOLID STATE
W/ INTERMITTENT
W/O TACHO- METER W/ TACHO- METER
WASHER LEVEL IND
WASHER SWITCH W/ INTERMITTENT W/O INTERMITTENT
WHT WIRE
WIPER FUSE
YEL WIRE
Go to component -> Wiper/washer circuit -> COMBINATION SWITCH COMB- INATION METER 17 2
