Courtesy lamps circuit, hatchback for Toyota Corolla XII (2018-2024)

BACK DOOR LOCK W/ COURTESY LIGHT SWITCH ASSEMBLY BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COURTESY DOME CUT RELAY DOME FUSE ECU-ACC FUSE ECU-DCC 2 FUSE GRY WIRE HOT AT ALL TIMES HOT W/ ACC RELAY ENERGIZED INSTRUMENT PANEL J/B ASSEMBLY LCTY LEFT "C" PILLAR) LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY LEFT FRONT DOOR LOCK W/ MOTOR ASSEMBLY LEFT REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY LEFT REAR DOOR LOCK W/ MOTOR ASSEMBLY LSSR LT GRN WIRE MAIN BODY ECU RCTY RED WIRE RELAY ENERGIZED RIGHT REAR DOOR LOCK W/ MOTOR ASSEMBLY VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

BLU WIRE BRN WIRE CTY DOOR DOOR LIGHT SWITCH DOOR LINKED SWITCH GRN WIRE GRY WIRE LEFT VANITY LIGHT ASSEMBLY LEFT VISOR ASSEMBLY LSSR LT GRN WIRE LUGGAGE COMPARTMENT LIGHT ASSEMBLY 1 MAIN BOARD MAP LIGHT ASSEMBLY OFF RED WIRE RIGHT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY RIGHT FRONT DOOR LOCK W/ MOTOR ASSEMBLY RIGHT REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY RIGHT VANITY LIGHT ASSEMBLY RIGHT VISOR ASSEMBLY RLMP ROOM LIGHT ASSEMBLY 1 VIO WIRE WHT/BLK WIRE YEL WIRE
