Headlights circuit, hatchback for Toyota Corolla XII (2018-2024)

AHID AUTO AUTOMATIC LIGHT CONTROL SENSOR BLK WIRE BLK/RED WIRE BLU WIRE BRN WIRE CANADA CLTB CLTE CLTS COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM DIMMER SWITCH DRL ECU-ACC FUSE ECU-B 2 FUSE ECU-DCC 2 FUSE EL BFG FLASH HIGH FOG SWITCH FUSIBLE LINK BLOCK ASSEMBLY GRN WIRE GRY WIRE HEAD HEAD DRL OFF OFF HF LOW HOT AT ALL TIMES HOT W/ HOT W/ ACC RELAY ENERGIZED HU LOW IA (LEFT SIDE OF DASH) INSTRUMENT PANEL J/B ASSEMBLY J/B-AM FUSE L OFF LCTY LIGHT CONTROL SWITCH LIGHT IC LLEW LT GRN WIRE MAIN BODY ECU PNK WIRE RCTY RED WIRE RLEW STEERING SENSOR STEERING WHEEL SWITCH HOUSING TAIL TAIL FUSE TAIL RELAY TURN SIGNAL SWITCH USA W/ ADAPTIVE FRONT LIGHTING SYSTEM W/O ADAPTIVE FRONT-LIGHTING SYSTEM WHT WIRE WHT/BLK WIRE YEL WIRE

BLK WIRE BLU WIRE BRAKE ACTUATOR ASSEMBLY BRN WIRE CANH PNK LINS WIRE COMPUTER DATA LINES SYSTEM ECUB ELECTRIC PARKING BRAKE SWITCH ASSEMBLY FAN FR FOG RELAY GRN WIRE GRY WIRE HOLD SWITCH HZRI IND LEFT FOG LIGHT ASSEMBLY LEFT HEADLIGHT UNIT ASSEMBLY LEFT REAR HEIGHT CONTROL SENSOR SUB-ASSEMBLY LEVELING, SWIVEL MOTOR LINL LINS LOCK SWITCH LOW/HIGH DRL LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK WIRE POL R/B ASSEMBLY 3 RED WIRE RELEASE SWITCH RIGHT FOG LIGHT ASSEMBLY RIGHT HEADLIGHT UNIT ASSEMBLY SBR SGR SHB SHG SHRL SHRR W/ ADAPTIVE FRONT LIGHTING SYSTEM WHT WIRE WHT/BLK WIRE YEL WIRE

AUTO HIGH BEAM SWITCH (IF EQUIPPED) AZBI BLK WIRE BLU WIRE DIM RELAY ENGINE ROOM J/B 1 ENGINE ROOM R/B 1 FOG FR FUSE GRN WIRE H-LP HI FUSE H-LP LH FUSE H-LP LH RELAY H-LP RH FUSE H-LP RH RELAY HIGH/LOW DRL HOT AT ALL TIMES IND LEFT HEADLIGHT UNIT ASSEMBLY (W/O ADAPTIVE FRONT LIGHTING SYSTEM) LT BLU WIRE LT GRN WIRE PNK WIRE RED WIRE RIGHT HEADLIGHT UNIT ASSEMBLY (W/O ADAPTIVE FRONT LIGHTING SYSTEM) SOL + VIO WIRE W/ ADAPTIVE FRONT LIGHTING SYSTEM W/O ADAPTIVE FRONT-LIGHTING SYSTEM WHT WIRE WHT/BLK WIRE YEL WIRE
