Toyota Corolla XI facelift (2015-2019) Charging circuit, w/ valvematic

ACC FUSE ALT FUSE BATTERY BLK/BLU WIRE BLK/DK GRN WIRE BLK/RED WIRE BRN WIRE CAN CONTROLLER CAN I/F CHARGE IND COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM CVT DISPLAY DRIVER DRIVER SIDE JUNCTION BLOCK ASSEMBLY ENGINE ROOM JUNCTION BLOCK ENGINE ROOM RELAY BLOCK GENERATOR CONTROL ECU ASSEMBLY GENERATOR W/ REGULATOR ASSEMBLY GRN WIRE GRY WIRE HOT W/ ACC RELAY ENERGIZED ICS FUSE INH LED DRIVER LIN 1 LT GRN WIRE M/T MAIN FUSIBLE LINK METER FUSE PNK WIRE RED WIRE RELAY ENERGIZED STARTER ASSEMBLY W/ LED WHT WIRE WIPER/WASHER SYSTEM
