Toyota Corolla XI facelift (2015-2019) left front occupant classification sensor Wiring diagram
This page shows the only wiring diagram for the component.left front occupant classification sensor, which is found in the car Toyota Corolla XI facelift (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front occupant classification sensor (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
BSW
BUCKLE SWITCH
CAN CONTROLLER
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DBKL
DIA
DRIVER SIDE JUNCTION BLOCK ASSEMBLY
ECU-B 2 FUSE
ECU-B FUSE
ENGINE ROOM RELAY BLOCK
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LC (RIGHT "C" PILLAR)
LED DRIVER
LEFT FRONT OCCUPANT CLASSIFICATION SENSOR
LEFT FRONT SEAT INNER BELT ASSEMBLY
LEFT OCCUPANT CLASSIFICATION SENSOR
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU
OCCUPANT DETECTION ECU
PNK BGND WIRE
PNK WIRE
RED WIRE
RIGHT FRONT AIR BAG SENSOR
RIGHT FRONT SEAT INNER BELT ASSEMBLY
SEAT BELT IND
SEAT SENSOR
SGD
SIG
SR-
SRS IND
SVC
TMMC MADE
TMMMS MADE
TMMMS MADE TMMC MADE
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (3 of 3) -> LEFT FRONT OCCUPANT CLASSIFICATION SENSOR
