Toyota Corolla XI facelift (2015-2019) left daytime running light assembly Wiring diagram
This page shows the only wiring diagram for the component.left daytime running light assembly, which is found in the car Toyota Corolla XI facelift (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left daytime running light assembly (1 of 1)
A/T CVT
BKUP LP RELAY
BLK WIRE
BRAKE FLUID LEVEL WARNING SWITCH (BRAKE MASTER CYLINDER RESERVOIR SUB-ASSEMBLY)
BRN WIRE
COMPRESSOR W/ PULLEY ASSEMBLY
COOLING FAN ECU
DATA LINK CONNECTOR 3
DEF RELAY
EFI MAIN RELAY
FAN RELAY 1
FRONT WIPER DEICER (WINDSHIELD GLASS)
FUEL PUMP CONTROL ECU ASSEMBLY
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGT/INJ RELAY
LEFT DAYTIME RUNNING LIGHT ASSEMBLY
LEFT FOG LIGHT ASSEMBLY
LEFT HEADLIGHT ASSEMBLY
LEVEL WARNING SWITCH ASSEMBLY
MILLIMETER WAVE RADAR SENSOR ASSEMBLY
POWER STEERING ECU ASSEMBLY
QUICK HEATER ASSEMBLY
REAR WINDOW DEFOGGER (BACK WINDOW GLASS)
RIGHT END OF DASH)
ST RELAY 1
TOP OF ENGINE)
VACUUM WARNING SWITCH ASSEMBLY
W/ A/C SWITCH
W/ VALVEMATIC
W/O LED W/ LED
WHT WIRE
WHT/BLK WIRE
WIRELESS DOOR LOCK BUZZER
Go to component -> Ground distribution circuit (1 of 5) -> LEFT DAYTIME RUNNING LIGHT ASSEMBLY
