Toyota Corolla XI facelift (2015-2019) cvt w/o paddle shift switch cvt w/ paddle shift switch Wiring diagram
This page shows the only wiring diagram for the component.cvt w/o paddle shift switch cvt w/ paddle shift switch, which is found in the car Toyota Corolla XI facelift (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cvt w/o paddle shift switch cvt w/ paddle shift switch (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CVT W/O PADDLE SHIFT SWITCH CVT W/ PADDLE SHIFT SWITCH
DOWN
GRN WIRE
GRY WIRE
LEFT STEERING PAD SWITCH ASSEMBLY
LT GRN WIRE
ORG/ WIRE
PATTERN SELECT SWITCH ASSEMBLY
PNK WIRE
RED WIRE
RIGHT STEERING PAD SWITCH ASSEMBLY
RIGHT STEERING SWITCH
SFTD
SFTU
SPIRAL CABLE SUB-ASSEMBLY
STEERING PAD SWITCH ASSEMBLY
TRANSMISSION CONTROL SWITCH (TRANSMISSION FLOOR SHIFT ASSEMBLY)
TRANSMISSION REVOLUTION SENSOR (PRIMARY)
TRANSMISSION REVOLUTION SENSOR (SECONDARY)
TRANSMISSION SHIFT SWITCH ASSEMBLY
VIO WIRE
W/ DYNAMIC RADAR CRUISE CONTROL W/O DYNAMIC RADAR CRUISE CONTROL
W/ PADDLE SHIFT SWITCH
W/O PADDLE SHIFT SWITCH
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Transmission circuit, w/ valvematic (2 of 3) -> CVT W/O PADDLE SHIFT SWITCH CVT W/ PADDLE SHIFT SWITCH
