Toyota Corolla XI facelift (2015-2019) can controller Wiring diagrams
This page contains all the electrical diagrams for the component. can controller, in which he is found in the car Toyota Corolla XI facelift (2015-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram can controller (1 of 21)
ACC FUSE
ALT FUSE
BATTERY
BLK/BLU WIRE
BLK/DK GRN WIRE
BLK/RED WIRE
BRN WIRE
CAN CONTROLLER
CAN I/F
CHARGE IND
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
CVT
DISPLAY DRIVER
DRIVER SIDE JUNCTION BLOCK ASSEMBLY
ENGINE ROOM JUNCTION BLOCK
ENGINE ROOM RELAY BLOCK
GENERATOR CONTROL ECU ASSEMBLY
GENERATOR W/ REGULATOR ASSEMBLY
GRN WIRE
GRY WIRE
HOT W/ ACC RELAY ENERGIZED
ICS FUSE
INH
LED DRIVER
LIN 1
LT GRN WIRE
M/T
MAIN FUSIBLE LINK
METER FUSE
PNK WIRE
RED WIRE
RELAY ENERGIZED
STARTER ASSEMBLY
W/ LED
WHT WIRE
WIPER/WASHER SYSTEM
Go to component -> Charging circuit, w/ valvematic -> CAN CONTROLLER
Wiring diagram can controller (2 of 21)
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER
CAN CONTROLLER
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DETECTION
DOOR IND
DRIVER DISPLAY
DRIVER SIDE JUNCTION BLOCK ASSEMBLY
ECU-B 2 FUSE
ENGINE ROOM RELAY BLOCK
GRN WIRE
HOT AT ALL TIMES
KEY
LED DRIVER
LEFT FRONT DOOR LOCK W/ MOTOR ASSEMBLY
LEFT REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY
LOCK
LSSR
LT BLU WIRE
LT GRN WIRE
METER FUSE
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY
RIGHT FRONT DOOR LOCK W/ MOTOR ASSEMBLY
RIGHT REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY
UN-
UN-LOCK WARNING SWITCH ASSEMBLY
UNLOCK
VIO WIRE
W/ WIRELESS DOOR LOCK CONTROL
W/O TFT DISPLAY
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Forced entry circuit, w/o smart key system (2 of 3) -> CAN CONTROLLER
Wiring diagram can controller (3 of 21)
BLK WIRE
BLU WIRE
BRAKE ACTUATOR ASSEMBLY
BRN WIRE
BUZZER
CAN CONTROLLER
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DETECTION
DOOR IND
DRIVER DISPLAY
DRIVER SIDE JUNCTION BLOCK ASSEMBLY
ELECTRICAL
IND
KEY
KEY IND
LED DRIVER
LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY
LEFT FRONT DOOR LOCK W/ MOTOR ASSEMBLY
LEFT REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY
LOCK
LSSR
LT BLU WIRE
LT GRN WIRE
MASTER
METER FUSE
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT FRONT DOOR LOCK W/ MOTOR ASSEMBLY
UNLOCK
VIO WIRE
W/ TFT DISPLAY W/O TFT DISPLAY W/ VSC W/O VSC
W/ WIRELESS DOOR LOCK CONTROL
WHT WIRE
WHT/BLK WIRE
WIRELESS DOOR LOCK BUZZER
YEL WIRE
Go to component -> Forced entry circuit, w/ smart key system (2 of 5) -> CAN CONTROLLER
Wiring diagram can controller (4 of 21)
A/B FUSE
ACC FUSE
AIR BAG SENSOR ASSEMBLY
AUTO DRL DRL OFF OFF
BGND
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BSW
BUCKLE SWITCH
BUZZER
CAN CONTROLLER
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DBKL
DOOR IND
DRIVER SIDE JUNCTION BLOCK ASSEMBLY
ECU- IG 1 FUSE
ECU-B 2 FUSE
ECU-B FUSE
ENGINE ROOM RELAY BLOCK
EXCEPT USA TMMMS MADE TMMC MADE 6 7 8
GRN WIRE
GRY WIRE
HEAD
HEADLIGHT DIMMER SWITCH ASSEMBLY
HOT AT ALL TIMES
HOT W/
LED DRIVER
LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY
LEFT FRONT SEAT INNER BELT ASSEMBLY
LIGHT CONTROL SWITCH
LT GRN WIRE
MAIN BODY ECU
METER FUSE
OCCUPANT DETECTION ECU
PARKING BRAKE SWITCH ASSEMBLY
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT FRONT SEAT INNER BELT ASSEMBLY
SEAT BELT IND
TAIL
TRANSPONDER KEY ECU ASSEMBLY
UNLOCK WARNING SWITCH ASSEMBLY
VIO WIRE
W/ AUTOMATIC LIGHT CONTROL W/O AUTOMATIC LIGHT CONTROL USA
W/ DYNAMIC RADAR CRUISE CONTROL W/O DYNAMIC RADAR CRUISE CONTROL
WHT WIRE
WHT/BLK WIRE
Go to component -> Key reminder & seat belt warning circuit -> CAN CONTROLLER
Wiring diagram can controller (5 of 21)
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER
CAN CONTROLLER
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DETECTION
DOOR IND
DRIVER DISPLAY
DRIVER SIDE JUNCTION BLOCK ASSEMBLY
ECU-B 2 FUSE
ENGINE ROOM RELAY BLOCK
GRN WIRE
HOT AT ALL TIMES
KEY
LED DRIVER
LEFT FRONT DOOR LOCK W/ MOTOR ASSEMBLY
LEFT REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY
LOCK
LSSR
LT BLU WIRE
LT GRN WIRE
METER FUSE
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY
RIGHT FRONT DOOR LOCK W/ MOTOR ASSEMBLY
RIGHT REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY
UN-
UN-LOCK WARNING SWITCH ASSEMBLY
UNLOCK
VIO WIRE
W/ WIRELESS DOOR LOCK CONTROL
W/O TFT DISPLAY
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power door locks circuit, w/o smart key system (2 of 3) -> CAN CONTROLLER
Wiring diagram can controller (6 of 21)
BLK WIRE
BLU WIRE
BRAKE ACTUATOR ASSEMBLY
BRN WIRE
BUZZER
CAN CONTROLLER
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DETECTION
DOOR IND
DRIVER DISPLAY
DRIVER SIDE JUNCTION BLOCK ASSEMBLY
ELECTRICAL
IND
KEY
KEY IND
LED DRIVER
LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY
LEFT FRONT DOOR LOCK W/ MOTOR ASSEMBLY
LEFT REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY
LOCK
LSSR
LT BLU WIRE
LT GRN WIRE
MASTER
METER FUSE
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT FRONT DOOR LOCK W/ MOTOR ASSEMBLY
UNLOCK
VIO WIRE
W/ TFT DISPLAY W/O TFT DISPLAY W/ VSC W/O VSC
W/ WIRELESS DOOR LOCK CONTROL
WHT WIRE
WHT/BLK WIRE
WIRELESS DOOR LOCK BUZZER
YEL WIRE
Go to component -> Power door locks circuit, w/ smart key system (2 of 5) -> CAN CONTROLLER
Wiring diagram can controller (7 of 21)
ACC FUSE
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER
CAN CONTROLLER
CAN I/F
CERTIFICATION ECU
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
CSEL
DATA
DRIVER SIDE JUNCTION BLOCK ASSEMBLY
ECU-B 2 FUSE
ECU-B FUSE
ECU-IG 3 FUSE
ENGINE ROOM RELAY BLOCK
GRN WIRE
HOT AT ALL TIMES
HOT W/
HOT W/ ACC RELAY ENERGIZED
IG+ PNK WIRE
LED DRIVER
LT GRN WIRE
MAIN BODY ECU
METER FUSE
PNK WIRE
RCO
RDAM
RED WIRE
RELAY ENERGIZED
TIRE PRESSURE IND
TIRE PRESSURE WARNING RECEIVER ASSEMBLY
TIRE PRESSURE WARNING RESET SWITCH (TIRE PRESSURE WARNING SWITCH 1)
VIO WIRE
W/ SMART KEY SYSTEM W/O SMART KEY SYSTEM, W/ WIRELESS DOOR LOCK CONTROL
W/O SMART KEY SYSTEM W/ WIRELESS DOOR LOCK CONTROL
W/O SMART KEY SYSTEM, WIRELESS DOOR LOCK CONTROL
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Tire pressure monitoring circuit -> CAN CONTROLLER
Wiring diagram can controller (8 of 21)
A/T
ACC FUSE
BLK WIRE
BLU WIRE
BRN WIRE
CAN CONTROLLER
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
CVT
DIODE (BACKUP LIGHT)
DISPLAY DRIVER
DRIVER SIDE JUNCTION BLOCK ASSEMBLY
ECU-IG 2 FUSE
ECU-IG 3 FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
IGN FUSE
LED DRIVER
LT BLU WIRE
LT GRN WIRE
MASTER IND
METER FUSE
NSSD
PARK/NEUTRAL POSITION SWITCH ASSEMBLY (LEFT SIDE OF TRANSAXLE)
PNK WIRE
RED WIRE
RELAY ENERGIZED
SFTD
SFTU
SHIFT POSITION INDICATOR
SPORT IND
STARTING/ CHARGING SYSTEM
STOP FUSE
STOP LIGHT SWITCH ASSEMBLY
THROTTLE BODY ASSEMBLY
TRANSMISSION CONTROL SWITCH
TRANSMISSION CONTROL SWITCH (TRANSMISSION FLOOR SHIFT ASSEMBLY)
TRANSMISSION FLOOR SHIFT ASSEMBLY
VIO WIRE
W/ TFT DISPLAY
W/O PADDLE SHIFT SWITCH
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Transmission circuit, w/ dual vvt-i (2 of 3) -> CAN CONTROLLER
Wiring diagram can controller (9 of 21)
ACC FUSE
BLK WIRE
BLU WIRE
BRN WIRE
CAN CONTROLLER
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DIODE (BACKUP LIGHT)
DISPLAY DRIVER
DRIVER SIDE JUNCTION BLOCK ASSEMBLY
ECU-IG 2 FUSE
ECU-IG 3 FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
IGN FUSE
LT GRN WIRE
METER FUSE
NSSD
PARK/NEUTRAL POSITION SWITCH ASSEMBLY (LEFT SIDE OF TRANSAXLE)
PNK WIRE
RED WIRE
RELAY ENERGIZED
SHIFT POSITION INDICATOR
STARTING/ CHARGING SYSTEM
STOP FUSE
STOP LIGHT SWITCH ASSEMBLY
THROTTLE BODY ASSEMBLY
TRANSMISSION CONTROL SWITCH
TRANSMISSION FLOOR SHIFT ASSEMBLY
VIO WIRE
W/ DYNAMIC RADAR CRUISE CONTROL W/O DYNAMIC RADAR CRUISE CONTROL
W/O PADDLE SHIFT SWITCH
WHT WIRE
WHT/BLK WIRE
Go to component -> Transmission circuit, w/ valvematic (3 of 3) -> CAN CONTROLLER
Wiring diagram can controller (10 of 21)
BLK WIRE
BLU WIRE
BRN WIRE
CAN CONTROLLER
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DRIVER SIDE JUNCTION BLOCK ASSEMBLY
ENGINE ROOM RELAY BLOCK
FAST
FRONT WASHER SWITCH
FRONT WIPER SWITCH
GENERATOR CONTROL ECU ASSEMBLY
GRN WIRE
HOT W/
INH
INTERMITTENT TIMING SWITCH
LEVEL WARNING SWITCH ASSEMBLY
LO HI
LT GRN WIRE
METER FUSE
MIST OFF
PNK WIRE
RED WIRE
RELAY ENERGIZED
SLOW
W/ INTERMITTENT TIMING SWITCH
W/ VALVEMATIC
W/O INTERMITTENT TIMING SWITCH
WASHER FLUID RESERVOIR)
WASHER FUSE
WASHER LEVEL IND
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WASHER MOTOR, PUMP ASSEMBLY
WINDSHIELD WIPER MOTOR ASSEMBLY
WINDSHIELD WIPER SWITCH ASSEMBLY
WIP-S FUSE
WIPER FUSE
WIPER RELAY
Go to component -> Wiper/washer circuit -> CAN CONTROLLER
