Ground distribution circuit for Toyota Corolla XI (2012-2016)

A/T AA (BEHIND LEFT HEADLIGHT) AB (BEHIND LEFT HEADLIGHT) AE (LEFT END OF DASH) AF (RIGHT END OF DASH) BB (TOP OF ENGINE) BKUP LP DEF RELAY RELAY BLK WIRE BRAKE FLUID LEVEL WARNING SWITCH (BRAKE MASTER CYLINDER RESERVOIR SUB-ASSEMBLY) BRN WIRE COOLING FAN ECU CVT DATA LINK CONNECTOR 3 ENGINE CONTROL MODULE FAN ST RELAY 1 RELAY 1 IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 LE (LEFT TAIL LIGHT ASSEMBLY) LEFT HEADLIGHT ASSEMBLY POWER STEERING ECU ASSEMBLY QA (RIGHT "C" PILLAR) REAR WINDOW DEFOGGER (BACK WINDOW GLASS) RELAY ENGINE CONTROL MODULE W/ VALVEMATIC WHT WIRE WHT/BLK WIRE

BRN WIRE CENTER STOP LIGHT ASSEMBLY FRONT POWER SEAT SWITCH LA (LEFT "B" PILLAR) LB (LEFT "C" PILLAR) LC (RIGHT "C" PILLAR) LEFT FRONT SEAT CUSHION HEATER ASSEMBLY LEFT LICENSE PLATE LIGHT ASSEMBLY LEFT REAR COMBINATION LIGHT ASSEMBLY LEFT REAR DOOR LOCK W/ MOTOR ASSEMBLY LUGGAGE COMPARTMENT DOOR LOCK ASSEMBLY LUGGAGE ELECTRICAL KEY SWITCH RIGHT FRONT SEAT CUSHION HEATER ASSEMBLY RIGHT LICENSE PLATE LIGHT ASSEMBLY RIGHT REAR COMBINATION LIGHT ASSEMBLY RIGHT REAR DOOR LOCK W/ MOTOR ASSEMBLY TMMC MADE TMMMS MADE W/ TIRE PRESSURE WARNING SYSTEM W/ WIRELESS DOOR LOCK CONTROL W/O TIRE PRESSURE WARNING SYSTEM WHT/BLK WIRE

AC (BEHIND RIGHT HEADLIGHT) AD (BEHIND RIGHT HEADLIGHT) AIR FUEL RATIO SENSOR (BANK 1 SENSOR 1) SHIELD BA (TOP OF ENGINE) BATTERY BLK WIRE BLK/DK GRN WIRE BRAKE ACTUATOR ASSEMBLY BRN WIRE CA (BEHIND LEFT HEADLIGHT) CANISTER PUMP MODULE CB (LEFT SIDE OF TRANSAXLE) CRANK POSITION SENSOR SHIELD CRUISE CONTROL MAIN SWITCH CRUISE CONTROL SWITCH WIRE ENGINE CONTROL MODULE KNOCK CONTROL SENSOR (BANK 1) SHIELD NCA WIRE RIGHT HEADLIGHT ASSEMBLY SPIRAL CABLE SUB-ASSEMBLY (STEERING COLUMN) W/ CRUISE CONTROL W/ VSC W/O VSC WHT/BLK WIRE WINDSHIELD WIPER MOTOR ASSEMBLY

BRN WIRE CLOCK ASSEMBLY COMBINATION METER ASSEMBLY DOOR CONTROL SWITCH ASSEMBLY EC (RIGHT KICK PANEL) ED (RIGHT SIDE OF DASH) HAZARD WARNING SIGNAL SWITCH ASSEMBLY POWER OUTLET SOCKET ASSEMBLY 1 RIGHT OUTER REAR VIEW MIRROR ASSEMBLY TELLTALE LIGHT ASSEMBLY W/ NAVIGATION RECEIVER TYPE W/ RADIO RECEIVER TYPE W/ OUTER REAR VIEW MIRROR SIDE TURN SIGNAL LIGHT W/ RADIO, DISPLAY RECEIVER TYPE WHT/BLK WIRE

A/C AMPLIFIER ASSEMBLY AIR BAG SENSOR ASSEMBLY AUTOMATIC A/C BK/DR LOCK D/LOCK RELAY RELAY BLK WIRE BLK/ WHT WIRE BRN WIRE COMBINATION METER ASSEMBLY D DOOR D/UNLOCK RELAY DOME LIGHT (ROOM LIGHT ASSEMBLY 1) DRIVER'S SIDE JUNCTION BLOCK ASSEMBLY (LEFT END EB (CENTER OF DASH) ECO SWITCH ASSEMBLY HEADLIGHT DIMMER SWITCH ASSEMBLY INNER REAR MAP LIGHT VIEW MIRROR ASSEMBLY ASSEMBLY LEFT FRONT DOOR LOCK W/ MOTOR ASSEMBLY LEFT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY LEFT OUTER REAR VIEW MIRROR ASSEMBLY LEFT SEAT HEATER SWITCH MAIN UNLOCK BODY RELAY 1 RELAY ECU MANUAL A/C OF DASH) OUTER DATA MIRROR LINK SWITCH CONNECTOR ASSEMBLY PATTERN SELECT SWITCH ASSEMBLY POWER RELAY 3 RELAY RELAY POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY RELAY 2 RIGHT SEAT HEATER SWITCH SPIRAL CABLE STEERING PAD SWITCH ASSEMBLY COMBINATION METER ASSEMBLY SUB- ASSEMBLY (STEERING COLUMN) TRANSMISSION CONTROL SWITCH (TRANSMISSION FLOOR SHIFT ASSEMBLY) UN-LOCK WARNING SWITCH ASSEMBLY W/ FRONT FOG LIGHT W/ OUTER REAR VIEW MIRROR SIDE TURN SIGNAL LIGHT W/ PADDLE SHIFT SWITCH, CVT W/ SLIDING ROOF WHT WIRE WHT/BLK WIRE WINDSHIELD WIPER SWITCH ASSEMBLY
