Toyota Corolla XI (2012-2016) continuously variable valve lift controller assembly (rear of engine compt) wiring diagram
This page shows the only wiring diagram for the component.continuously variable valve lift controller assembly (rear of engine compt), which is found in the car Toyota Corolla XI (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
continuously variable valve lift controller assembly (rear of engine compt) wiring diagram (1 of 1)
AB (BEHIND LEFT HEADLIGHT)
ACCELERATOR PEDAL SENSOR ASSEMBLY
ANTI-THEFT SYSTEM DOOR LOCKS SYSTEM COMPUTER DATA LINES SYSTEM
BLK WIRE
BLU WIRE
BRN WIRE
CAN (+)
COMPUTER DATA LINES SYSTEM
CONTINUOUSLY VARIABLE VALVE LIFT CONTROLLER ASSEMBLY (REAR OF ENGINE COMPT)
COOLING FANS SYSTEM
CRUISE CONTROL SYSTEM
DRIVER'S SIDE
EC VPA EPA VCPA
ECM (LEFT SIDE OF ENGINE COMPT)
EFI MAIN FUSE
EFI MAIN RELAY
FP-
FPC
FPC STA TC
FUEL PUMP CONTROL ECU ASSEMBLY (LEFT REAR LUGGAGE COMPT)
GAUGE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM RELAY BLOCK (LEFT SIDE OF ENGINE COMPT)
HOT W/ TAIL RELAY ENERGIZED
IGN FUSE
IGT/ INJ RELAY
INJ FUSE
INSTRUMENT CLUSTER SYSTEM
JUNCTION BLOCK ASSEMBLY (LEFT END OF DASH)
LT BLU WIRE
LT GRN WIRE
MPMP
PNK 19 20 WIRE
PNK IMI IMO NEO TACH WIRE
PNK SDSW WIRE
PNK WIRE
PUMP FUEL SUCTION W/ PUMP, GAUGE TUBE ASSEMBLY (FUEL TANK ASSEMBLY)
RED WIRE
RELAY ENERGIZED
SDWN
SPD RFC MREL
STARTING/CHARGING SYSTEM
STOP FUSE
TAIL FUSE
VCPP PPMP EPPM IGSW
VIO WIRE
VPMP
WHT WIRE
WHT/BLK WIRE
YEL WIRE
