Car Wiring Diagrams for Heated seats circuit, tmc made for Toyota Corolla X facelift (2010-2013)

BLK WIRE GRN WIRE HOT IN ON OR START SEAT HTR FUSE ILL ILL INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) J/B 4 (RIGHT SIDE OF DASH) LEFT FRONT SEAT HEATER ASSEMBLY LEFT SIDE SEAT SWITCH ORG/ WIRE PNK WIRE RIGHT FRONT SEAT HEATER ASSEMBLY RIGHT SIDE SEAT SWITCH SEAT BACK) SEAT CUSHION) SEAT HEATER SWITCH WHT WIRE WHT/BLK WIRE
