Toyota Corolla X facelift (2010-2013) rdi fan fuse abs 1 fuse htr fuse Wiring diagram
This page shows the only wiring diagram for the component.rdi fan fuse abs 1 fuse htr fuse, which is found in the car Toyota Corolla X facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rdi fan fuse abs 1 fuse htr fuse (1 of 1)
ABS 3 FUSE
AIR CONDITIONING SYSTEM
AIR CONDITIONING, ANTI-THEFT SYSTEMS
AIR COOLING ANTI-LOCK CONDITIONING FANS BRAKES SYSTEM SYSTEM SYSTEM
ALT FUSE
ALT-S FUSE
BATTERY
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/YEL WIRE
DCC SHORT PIN
DOME FUSE
ECU-B FUSE
EFI MAIN FUSE
EFI MAIN RELAY
ELECTRONIC POWER STEERING SYSTEM
ENGINE CONTROLS SYSTEM
ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B (ENGINE ROOM J/B)
EPS FUSE
FROM ALT FUSE (DIAGRAM 1 OF 3)
FROM ENGINE ROOM J/B (DIAGRAM 1 OF 3)
FROM INSTRUMENT PANEL J/B (DIAGRAM 2 OF 3)
FUSE
FUSIBLE LINK MAIN (12 GA-
GRN WIRE
GRY WIRE
H-LP- MAIN FUSE
HEADLIGHTS SYSTEM
HEADLIGHTS, AIR CONDITIONING SYSTEMS
HORN FUSE
HORN RELAY
HTR SUB 3 FUSE HTR SUB 1 FUSE
IGNITION OR STARTER
INTERIOR LIGHTS, ANTI-THEFT, DOOR LOCKS SYSTEMS
J/C
NAVIGATION, SOUND SYSTEMS
ON LOCK OFF
P/I FUSE
PNK WIRE
RAD 1 FUSE
RDI FAN FUSE ABS 1 FUSE HTR FUSE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RELAY
SHIFT INTERLOCK SYSTEM
STARTING/ CHARGING SYSTEM
STARTING/ EXTERIOR CHARGING LIGHTS SYSTEM SYSTEM
SWITCH ASSEMBLY (W/O SMART KEY SYSTEM)
TO ABS 3 FUSE (DIAGRAM 1 OF 3)
TO ENGINE ROOM J/B (DIAGRAM 1 OF 3)
TO INSTRUMENT PANEL J/B (DIAGRAM 2 OF 3)
TO INSTRUMENT PANEL J/B (DIAGRAM 3 OF 3)
TO R/B 5 (DIAGRAM 3 OF 3)
TURN HAZ FUSE ETCS FUSE FUSE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Power distribution circuit, tmc made (1 of 3) -> RDI FAN FUSE ABS 1 FUSE HTR FUSE
