Toyota Corolla X facelift (2010-2013) rcty pcty dcty Wiring diagrams
This page contains all the electrical diagrams for the component. rcty pcty dcty, in which he is found in the car Toyota Corolla X facelift (2010-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
rcty pcty dcty wiring diagram (1 of 2)
19 18 SRX STX
5 4 21 IG ALTB
8 1 15 16 10 INDW INDS CANH CANL LSR
BLK WIRE
BLU WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DOME FUSE
DOOR FUSE
ECU- IG 1 FUSE
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM R/B ECU-B FUSE (ENGINE ROOM J/B)
HOT IN ON OR ACC
HOT IN ON OR START
IGN FUSE
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
KEY
LCTY
LED DRIVER
LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY (LEFT "B" PILLAR)
LEFT FRONT DOOR LOCK ASSEMBLY (DRIVER'S DOOR)
LEFT REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY (BASE OF LEFT "C" PILLAR)
LEFT REAR DOOR LOCK ASSEMBLY (LEFT REAR DOOR)
LOCK
LSSR
LSWP ACTD LSWD
LT GRN WIRE
MAIN BODY ECU INSTRUMENT PANEL J/B
ORG/ WIRE
PNK WIRE
RCTY PCTY DCTY
RED WIRE
RED/GRN WIRE
RIGHT FRONT DOOR LOCK ASSEMBLY (FRONT PASSENGER'S DOOR)
RIGHT REAR DOOR LOCK ASSEMBLY (RIGHT REAR DOOR)
SMART KEY IND
SWIL
UNLK
UNLK DETECTION
VIO WIRE
W/ RIGHT DOOR KEY LOCK, UNLOCK SWITCH
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Forced entry circuit, nummi made with smart key system (1 of 3) -> RCTY PCTY DCTY
