Toyota Corolla X facelift (2010-2013) navigation) radio receiver assembly Wiring diagram
This page shows the only wiring diagram for the component.navigation) radio receiver assembly, which is found in the car Toyota Corolla X facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram navigation) radio receiver assembly (1 of 1)
BLK WIRE
BRN WIRE
CENTER STOP LIGHT ASSEMBLY
CIGARETTE LIGHTER ASSEMBLY
COMBINATION METER ASSEMBLY
FRONT POWER OUTLET SOCKET
FUEL PUMP FUEL SENDER LEFT FRONT GAUGE SEAT HEATER ASSEMBLY ASSEMBLY
JUNCTION
LEFT BACKUP LIGHT BULB
LEFT LICENSE PLATE LIGHT ASSEMBLY
LEFT REAR COMBINATION LIGHT ASSEMBLY
LUGGAGE COMPARTMENT DOOR LOCK ASSEMBLY
NAVIGATION) RADIO RECEIVER ASSEMBLY
REAR WINDOW DEFOGGER
RIGHT BACKUP LIGHT BULB
RIGHT FRONT DOOR LOCK ASSEMBLY
RIGHT FRONT DOOR LOCK CONTROL SWITCH ASSEMBLY
RIGHT LICENSE PLATE LIGHT ASSEMBLY
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY
RIGHT REAR COMBINATION LIGHT ASSEMBLY
W/ RETRACTOR MIRROR
W/O
W/O RETRACTOR MIRROR
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit, tmc made (3 of 3) -> NAVIGATION) RADIO RECEIVER ASSEMBLY
