Toyota Corolla X (2006-2010) Charging circuit

ALT FUSE ALT-S FUSE BATTERY BLK WIRE BLK/WHT WIRE BLU WIRE CHARGE IND COMBINATION METER ENGINE ROOM J/B (ON LEFT SIDE OF ENGINE COMPT) FUSE GENERATOR GRN WIRE HOT AT ALL TIMES ENGINE ROOM R/B (INTEGRAL TO ENGINE ROOM J/B) IGNITION SWITCH INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH, AT LOWER FINISH PANEL) JUNCTION CONNECTOR 4, 5 (BEHIND RIGHT SIDE OF DASH) MAIN FUSE MAIN FUSIBLE LINK (14 GA- ORG/ WIRE RED WIRE RIGHT J/B (BEHIND UPPER RIGHT SIDE OF DASH) STARTING CIRCUIT WHT WIRE YEL WIRE
