Toyota Corolla VIII facelift (1997-2002) Warning system circuits

BLK WIRE BLU WIRE BLU/YEL WIRE CENTER J/B (BEHIND CENTER OF DASH) CIG FUSE COMBINATION METER SEAT BELT IND DOME FUSE DRIVER SIDE J/B (BEHIND LEFT KICK PANEL) GAUGE FUSE HOT AT ALL TIMES ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT) HOT IN ON OR HOT W/ COMBINATION SW IN TAIL OR HEAD INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH, AT LOWER FINISH PANEL) INTEGRATION RELAY J/C 19 (NEAR LEFT REAR TAILLIGHT) J/C 8 (BEHIND LOWER CENTER OF DASH, TAPED TO HARNESS) LEFT FRONT DOOR COURTESY SWITCH (IN LEFT "B" PILLAR) RED WIRE SEAT BELT RETRACTOR SWITCH TAIL FUSE UNLOCK WARNING SWITCH (ON STEERING COLUMN) WHT WIRE YEL WIRE
