Toyota Corolla VIII facelift (1997-2002) A/t circuit

1 10 16 BATT 2 5 8 14 17 18 23 VC 2 ODMS STP STA 8 3 DATA LINK CONNECTOR 1 (LEFT REAR OF ENGINE COMPT) BLK WIRE BLK/ORG WIRE BLK/WHT WIRE BLU/BLK WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/YEL WIRE CENTER J/B (BEHIND CENTER OF DASH) COMBINATION METER CRUISE CONTROL ECU (BEHIND RIGHT KICK PANEL) CRUISE CONTROL SYSTEM EFI OR F-HTR FUSE EFI OR F-HTR RELAY ELECTRONICALLY CONTROLLED TRANSMISSION SOLENOID ENGINE CONTROL MODULE (BELOW CENTER OF DASH) ENGINE COOLANT TEMPERATURE SENSOR (REAR OF ENGINE, ON COOLANT OUTLET) ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT) GAUGE FUSE GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN HOT IN ON OR START IGN FUSE INSTRUMENT PANEL J/B (LEFT SIDE OF DASH, AT LOWER FINISH PANEL) INTERGRATION RELAY J/C 1 (BEHIND LEFT KICK PANEL) J/C 11 (CENTER OF DASH) J/C 12 (CENTER OF DASH) J/C 9, J/C 10 (CENTER OF DASH) JAPAN PROD U.S. PROD LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE NSW ODLP SPD O/D MAIN SWITCH O/D OFF INDICATOR RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE SPEEDO- METER ST FUSE STOP FUSE STOPLIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) THROTTLE POSITION SENSOR (ON THROTTLE BODY ASSEMBLY) USA W/O ABS, SRS, CRUISE, TACH OTHERS VEHICLE SPEED SENSOR (ON TOP OF TRANSAXLE) VIO WIRE VIO/WHT WIRE W/ CRUISE CONTROL WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE
