Toyota Corolla VIII facelift (1997-2002) tmmc made nummi made Wiring diagram

2000 M/T A/C+ A/C A/C LA/C A/C AMPLIFIER (BEHIND DASH, ABOVE GLOVE BOX) A/C CONDENSER FAN MOTOR A/C EVAPORATOR TEMPERATURE SENSOR (BEHIND RIGHT SIDE OF DASH, ON EVAPORATOR) A/C FAN 2 RELAY A/C FAN 3 RELAY A/C FUSE A/C MAGNETIC CLUTCH, LOCK SENSOR A/C SWITCH AC MG RELAY ENGINE ROOM R/B 5 (ON LEFT FRONT OF ENGINE COMPARTMENT) ACT BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLOWER MOTOR (BELOW RIGHT SIDE OF DASH, IN HEATER-A/C HOUSING) BLOWER RESISTOR (BELOW RIGHT SIDE OF DASH, IN HEATER-A/C HOUSING) BLOWER SWITCH BLU WIRE BLU/BLK WIRE BLU/RED WIRE CDS FUSE CENTER J/B (BEHIND CENTER OF DASH) DEF DUAL J/C 14 ECU-IG FUSE ENGINE CONTROL MODULE ENGINE ROOM J/B (ON LEFT SIDE OF ENGINE COMPARTMENT) FAN FAN NO.1 RELAY GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN ON OR START HOT IN ON OR START RDI FUSE HTR FUSE HTR RELAY IGN GND ACT A/C TE LED LOCK MGC SG INTEGRATION RELAY J/C 1 (BEHIND LEFT KICK PANEL, TAPED TO HARNESS) J/C 10 (BEHIND CENTER OF DASH) J/C 13 (BEHIND UPPER RIGHT SIDE OF DASH) J/C 14 (RIGHT KICK PANEL) J/C 8 (LEFT DASH BRACE) LO OFF LT GRN WIRE LT GRN/BLK WIRE LT TMMC MADE NUMMI MADE NUMMI MADE TMMC MADE ORG/ WIRE PRS RADIATOR FAN MOTOR RED WIRE RED/BLU WIRE SINGLE TACH TMMC MADE NUMMI MADE WATER TEMPERATURE SWITCH (ON LEFT FRONT OF ENGINE, ON COOLANT OUTLET) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
