Back-up lamps circuit for Toyota Corolla VIII (1995-2000)
Back-up lamps circuit
2 2 6 (M/T) (4-A/T) (3-A/T)
BACK-UP LIGHT SWITCH (ON TRANSAXLE)
CENTER J/B (BEHIND CENTER OF DASH)
DRIVER SIDE J/B (BEHIND LEFT KICK PANEL)
INTEG- RATION RELAY
J/C 18 (ABOVE LEFT REAR WHEELWELL)
J/C 9, 10 (BEHIND LOWER CENTER OF DASH, TAPED TO HARNESS)
LEFT BACK-UP LIGHT
RED/BLK WIRE
RED/BLU WIRE
RIGHT BACK-UP LIGHT
WHT/BLK WIRE
