Toyota Corolla VIII (1995-2000) light control switch Wiring diagram
This page shows the only wiring diagram for the component.light control switch, which is found in the car Toyota Corolla VIII (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram light control switch (1 of 1)
4 4 FUSIBLE LINK BOX (TOP LEFT SIDE OF ENGINE ROOM J/B)
ALT FUSE
BLK WIRE
COMBINATION SWITCH
DAYTIME RUNNING LIGHT RELAY (MAIN) (BEHIND DASH, ABOVE GLOVE BOX)
DRIVER SIDE J/B (LEFT KICK PANEL)
DRIVER SIDE R/B (LEFT KICK PANEL)
ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HAZ FUSE
HAZARD SWITCH
HEAD TAIL
HIGH MOUNTED STOP LIGHT
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH, AT LOWER FINISH PANEL)
J/C 1 (BEHIND LEFT KICK PANEL, TAPED TO HARNESS)
J/C 14 (RIGHT KICK PANEL, TAPED TO HARNESS)
J/C 18 (BOTTOM OF LEFT "C" PILLAR)
J/C 19 (NEAR LEFT REAR TAILLIGHT)
J/C 8 (LOWER CENTER OF DASH, TAPED TO HARNESS)
JAPAN PROD USA PROD
LEFT FRONT PARK/ TURN LIGHT
LEFT REAR COMBIN- ATION LIGHT
LH RH
LICENSE PLATE LIGHT RIGHT REAR COMBIN- ATION LIGHT
LIGHT CONTROL SWITCH
LT GRN WIRE
LT LT
METER COMBINATION
OFF
ON OFF OFF
RED WIRE
RIGHT FRONT PARK/ TURN LIGHT
STOP
STOP FUSE
STOP TAIL
STOP- LIGHT SWITCH (ON BRACKET,
TAIL
TAIL FUSE
TAILLIGHT RELAY
TURN FUSE
TURN SIGNAL INDICATOR LIGHTS
TURN SIGNAL SWITCH
TURN TURN
TURN TURN TURN TURN SIGNAL SIGNAL SIGNAL SIGNAL FLASHER FLASHER FLASHER FLASHER
W/O DAYTIME RUNNING LIGHTS W/ DAYTIME RUNNING LIGHTS
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Exterior lamps circuit -> LIGHT CONTROL SWITCH
