Toyota Corolla VIII (1995-2000) hot w/ combination sw in tail or head Wiring diagram
This page shows the only wiring diagram for the component.hot w/ combination sw in tail or head, which is found in the car Toyota Corolla VIII (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot w/ combination sw in tail or head (1 of 1)
BLK WIRE
BLU WIRE
BLU/YEL WIRE
CENTER J/B (BEHIND CENTER OF DASH)
CIG FUSE
COMBINATION METER SEAT BELT IND
DOME FUSE
DRIVER SIDE J/B (BEHIND LEFT KICK PANEL)
GAUGE FUSE
HOT AT ALL TIMES ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT)
HOT IN ON OR
HOT W/ COMBINATION SW IN TAIL OR HEAD
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH, AT LOWER FINISH PANEL)
INTEGRATION RELAY
J/C 19 (NEAR LEFT REAR TAILLIGHT)
J/C 8 (BEHIND LOWER CENTER OF DASH, TAPED TO HARNESS)
LEFT FRONT DOOR COURTESY SWITCH (IN LEFT "B" PILLAR)
RED WIRE
SEAT BELT RETRACTOR SWITCH
TAIL FUSE
UNLOCK WARNING SWITCH (ON STEERING COLUMN)
WHT WIRE
YEL WIRE
Go to component -> Warning system circuits -> HOT W/ COMBINATION SW IN TAIL OR HEAD
