Instrument illumination circuit for Toyota Corolla VII (1991-2002)

A/C SWITCH A/T SHIFT LEVER ILLUM ALT FUSE ASHTRAY ILLUM BLK WIRE BLOWER SWITCH CENTER J/B (BEHIND CENTER OF DASH) CIGARETTE LIGHTER ILLUM COMBINATION METER DRIVER SIDE J/B (LEFT KICK PANEL) FUSIBLE LINK BOX (TOP LEFT SIDE OF ENGINE ROOM J/B) GRN WIRE HAZARD SWITCH HOT AT ALL TIMES INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH, AT LOWER FINISH PANEL) INTEGRATION RELAY J/C 8 (BEHIND LOWER CENTER OF DASH) METER ILUM RADIO, PLAYER REAR WINDOW DEFOGGER SWITCH RHEOSTAT TAIL FUSE TAILLIGHT RELAY WHT WIRE
