Toyota Corolla VII (1991-2002) spd ac sta +b tach fc Wiring diagram
This page shows the only wiring diagram for the component.spd ac sta +b tach fc, which is found in the car Toyota Corolla VII (1991-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram spd ac sta +b tach fc (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 BATT ELS
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 VC VG THA THW NE+
A/C SYSTEM
ACT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
CRUISE CONTROL SYSTEM
DATA LINK CONNECTOR 1 (LEFT REAR OF ENGINE COMPT)
DATA LINK CONNECTOR 3 (LEFT SIDE OF DASH)
DEFOGGER SYSTEM EXTERIOR LIGHTS SYSTEM
ENGINE CONTROL MODULE (BELOW CENTER OF DASH)
ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT)
EVG VTA
GRN WIRE
GRN/RED WIRE
IDLO
J/C 12 (BEHIND LOWER CENTER OF DASH)
J/C 6 (BEHIND UPPER CENTER OF DASH)
LT GRN WIRE
NCA WIRE
NE+
PARK/NEUTRAL POSITION SWITCH (ON LEFT SIDE OF TRANSAXLE)
PNK WIRE
RED (OR WHT) WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
SIL
SPD AC STA +B TACH FC
VIO/WHT WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 1.8ls, 3 speed a/t & m/t (3 of 3) -> SPD AC STA +B TACH FC
