Toyota Corolla VII (1991-2002) main daytime running light relay Wiring diagram
This page shows the only wiring diagram for the component.main daytime running light relay, which is found in the car Toyota Corolla VII (1991-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram main daytime running light relay (1 of 1)
4 A/T 3 A/T, M/T
A/C FAN RELAY 2 HTR RELAY
A/C MAGNETIC CLUTCH, LOCK SENSOR
ABS ACTUATOR, ECU
BLK WIRE
BRAKE FLUID LEVEL WARNING SWITCH
BRN WIRE
CANADA
COMBINATION METER
DATA LINK CON- NECTOR 3
DRL RELAY
EFI OR F-HTR RELAY
ENGINE CONTROL MODULE
ENGINE HOOD COURTESY SWITCH
ENGINE MAIN RELAY
HEATED OXYGEN SENSOR (BANK 1 SENSOR 1) DATA LINK CON- NECTOR 1
HEATED OXYGEN SENSOR BANK 1 SENSOR 2
IDLE AIR CONTROL VALVE NOISE FILTER
IGNITION COIL, IGNITER 1
IGNITION COIL, IGNITER 2
IGNITION COIL, IGNITER 3
IGNITION COIL, IGNITER 4
J/B 2 (BEHIND INSTRUMNET PANEL J/B)
J/C 1 (BEHIND LEFT KICK PANEL)
J/C 11
J/C 2 (BEHIND INSTR PANEL J/B)
LEFT FRONT TURN SIGNAL/ PARKING LIGHT
MAIN DAYTIME RUNNING LIGHT RELAY
RADIATOR FAN MOTOR
RIGHT FRONT TURN SIGNAL/ PARKING LIGHT
ST RELAY
THEFT- DETERRENT HORN
U.S.
W/O THEFT
WASHER LEVEL WARNING SWITCH
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (1 of 3) -> MAIN DAYTIME RUNNING LIGHT RELAY
