Toyota Corolla VII (1991-2002) ccs cms spd idl od mo gnd Wiring diagram

4 A/T A/T SHIFT LEVER POSITION SWITCH BLK WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRN WIRE BRN/YEL WIRE CCS CMS SPD IDL OD MO GND CENTER J/B (BEHIND CENTER OF DASH) COMBINATION METER COMBINATION SWITCH CRUISE CONTROL ACTUATOR (ON RIGHT REAR OF ENGINE COMPT) CRUISE CONTROL CLUTCH SWITCH (ON BRACKET, ABOVE CLUTCH PEDAL) CRUISE CONTROL ECU (BEHIND RIGHT KICK PANEL) CRUISE CONTROL IND CRUISE CONTROL SWITCH DATA LINK CONNECTOR 1 (ON LEFT REAR OF ENGINE COMPT) DRIVER SIDE J/B (BEHIND LEFT KICK PANEL) ECU-IG FUSE ENGINE CONTROL MODULE (BELOW CENTER OF DASH) GAUGE FUSE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN ON, START IDLO INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH, AT LOWER FINISH PANEL) INTEGRATION RELAY J/C 11 (BEHIND LOWER CENTER OF DASH) J/C 11 (BEHIND LOWER CENTER OF DASH, TAPED TO HARNESS) J/C 13 (BEHIND UPPER RIGHT SIDE OF DASH) J/C 14 (BEHIND RIGHT KICK PANEL) JUNCTION MAIN PI TC ECT MC PNK WIRE PNK/BLK WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RESUME/ ACCEL SET/ COAST SPEED- OMETER STOP FUSE STOPLIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) STP+ VEHICLE SPEED SENSOR (ON TOP OF TRANSAXLE) VIO WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE YEL WIRE
