Toyota Corolla VII (1991-2002) a/t shift lever illum Wiring diagram
This page shows the only wiring diagram for the component.a/t shift lever illum, which is found in the car Toyota Corolla VII (1991-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram a/t shift lever illum (1 of 1)
A/C SWITCH
A/T SHIFT LEVER ILLUM
ALT FUSE
ASHTRAY ILLUM
BLK WIRE
BLOWER SWITCH
CENTER J/B (BEHIND CENTER OF DASH)
CIGARETTE LIGHTER ILLUM
COMBINATION METER
DRIVER SIDE J/B (LEFT KICK PANEL)
FUSIBLE LINK BOX (TOP LEFT SIDE OF ENGINE ROOM J/B)
GRN WIRE
HAZARD SWITCH
HOT AT ALL TIMES
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH, AT LOWER FINISH PANEL)
INTEGRATION RELAY
J/C 8 (BEHIND LOWER CENTER OF DASH)
METER ILUM
RADIO, PLAYER
REAR WINDOW DEFOGGER SWITCH
RHEOSTAT
TAIL FUSE
TAILLIGHT RELAY
WHT WIRE
Go to component -> Instrument illumination circuit -> A/T SHIFT LEVER ILLUM
