Toyota Corolla VII (1991-2002) 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 ts Wiring diagram
This page shows the only wiring diagram for the component.16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 ts, which is found in the car Toyota Corolla VII (1991-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 ts (1 of 1)
+B TC
16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 BAT
16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 TS
ABS ACTUATOR, ECU (LEFT REAR OF ENGINE COMPT)
BLK WIRE
BLK/ORG WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
CENTER AIR BAG SENSOR ASSEMBLY (BELOW FRONT OF CENTER CONSOLE)
CRUISE CONTROL ECU (BEHIND RIGHT KICK PANEL)
DATA LINK CONNECTOR 1 (LEFT REAR OF ENGINE COMPT)
DATA LINK CONNECTOR 3 (BELOW LEFT SIDE OF DASH)
EFI OR F-HTR FUSE
EFI OR F-HTR RELAY
ENGINE CONTROL MODULE (BELOW CENTER OF DASH)
ENGINE CONTROL SYSTEM
ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPARTMENT)
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
J/C 6 (BEHIND UPPER CENTER OF DASH)
J/C 8
OBD FUSE
PNK/BLK WIRE
RED WIRE
SG CG
SIL
WHT WIRE
WHT/BLK WIRE
Go to component -> Computer data lines -> 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 TS
