Toyota Corolla IX facelift (2003-2007) Courtesy lamps circuit

3 12 13 LP BLK WIRE BLU WIRE BLU/WHT WIRE CENTER J/B (BEHIND CENTER OF DASH) COMBINATION METER DCTY DOOR DOOR FUSE DOOR IND ENGINE ROOM R/B (INTEGRAL TO ENGINE ROOM J/B) DOME FUSE GAUGE FUSE HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT PANEL J/B INTEGRATION RELAY INTERIOR LIGHT) J/C 10 (AT LEFT SIDE OF LUGGAGE COMPARTMENT) J/C 6 (BEHIND LEFT SIDE OF DASH) J/C 6 (BEHIND LEFT SIDE OF DASH) IE J/C 7 (AT RIGHT KICK PANEL) LEFT FRONT DOOR COURTESY SWITCH (AT LEFT "B" PILLAR) LEFT REAR DOOR COURTESY SWITCH (FORWARD OF LEFT REAR LUGGAGE COMPARTMENT LIGHT LUGGAGE COMPARTMENT LIGHT SWITCH (AT CENTER REAR OF LUGGAGE COMPARTMENT) OFF P-DR PCTY PERSONAL LIGHT RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE RHEOSTAT RIGHT FRONT DOOR COURTESY SWITCH (AT RIGHT "B" PILLAR) RIGHT REAR DOOR COURTESY SWITCH (FORWARD OF RIGHT REAR WHEELWELL) W/ DOOR LOCK CONTROL W/ MOON ROOF W/ AUTOMATIC GLARE- RESISTANT EC MIRROR W/O AUTOMATIC GLARE- RESISTANT EC MIRROR W/O DOOR LOCK CONTROL W/O DOOR LOCK CONTROL W/ DOOR LOCK CONTROL W/O MOON- ROOF WHEELWELL) WHT WIRE WHT/BLK WIRE
