Toyota Corolla IX facelift (2003-2007) Cooling fan circuit

BLK/RED WIRE BLK/WHT WIRE BLU/WHT WIRE BRN WIRE DUAL EA (AT FRONT SIDE OF RIGHT FENDER) ECU-IG FUSE ED (ON LEFT FRONT SUSPENSION TOWER) ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH, BELOW GLOVE BOX) ENGINE COOLANT TEMPERATURE SENSOR (ON REAR OF ENGINE, ON COOLANT OUTLET) ENGINE ROOM R/B (INTEGRAL TO ENGINE ROOM J/B) EXCEPT XRS FAN FAN 1 RELAY FAN 2 RELAY HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH, AT LOWER FINISH PANEL) J/C 2, 3 (BEHIND RIGHT SIDE OF DASH) LT GRN WIRE LT GRN/BLK WIRE OF ENGINE COMPT) PRESSURE SWITCH (AT RIGHT SIDE OF ENGINE COMPT) RADIATOR FAN MOTOR (BEHIND LEFT SIDE OF RADIATOR) RADIATOR FAN RESISTOR (AT LEFT FRONT RDI FAN FUSE SINGLE WHT WIRE WHT/BLK WIRE WHT/RED WIRE XRS YEL WIRE
