Toyota Corolla IX facelift (2003-2007) Computer data lines circuit

16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 BAT WFSE CANL TC TS PNK WIRE AIR BAG SENSOR ASSEMBLY (UNDER FRONT OF CENTER CONSOLE) BLK WIRE BLU/RED WIRE BRN WIRE CANL CANH CENTER J/B (BEHIND CENTER OF DASH) CRUISE CONTROL ECU (BEHIND LEFT SIDE OF DASH) D/G DATA LINK CONNECTOR 3 (BELOW LEFT END OF DASH) DIA EB (AT LEFT REAR OF ENGINE) ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH, BELOW GLOVE BOX) EOM EXCEPT XRS GRY WIRE HOT AT ALL TIMES INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH, AT LOWER FINISH PANEL) J/C 4, 5 (BEHIND RIGHT SIDE OF DASH) J/C 6 (BEHIND LEFT SIDE OF DASH) J/C-11 (BEHIND RIGHT SIDE OF DASH) OBD FUSE OCCUPANT CLASSIFICATION ECU (BELOW CENTER CONSOLE, FORWARD OF PARK BRAKE LEVER) PNK W/ VSC WIRE PNK W/O VSC WIRE PNK WIRE PNK/BLK WIRE RED/BLK WIRE RIGHT J/B (BEHIND UPPER RIGHT SIDE OF DASH) SIL SIL CANH SG CG SKID CONTROL ECU WITH ACTUATOR (AT RIGHT FRONT SIDE OF ENGINE COMPARTMENT) STEERING SENSOR (RIGHT SIDE OF STEERING COLUMN) TRANSPONDER KEY COMPUTER (BEHIND LEFT SIDE OF DASH) W/ VSC W/O VSC WFSE WHT WIRE WHT/BLK WIRE XRS YAW RATE SENSOR (LEFT SIDE OF CENTER CONSOLE)
