Power distribution circuit for Toyota Corolla IX (2000-2004)

A/C CONDENSER FAN MOTOR A/C FUSE A/C TRIPLE PRESSURE SWITCH, A/C SWITCH, A/C M/G RELAY ABS ACTUATOR, ECU ABS FUSE ALT FUSE ALT-S FUSE BATTERY BLK WIRE BLOWER MOTOR BLU WIRE CENTER J/B (BEHIND INSTRUMENT CLUSTER) DOME FUSE HORN FUSE EFI OR F-HTR FUSE EFI OR F-HTR RELAY ENGINE CONTROL MODULE ENGINE MAIN RELAY ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT) ENGINE ROOM R/B 5 (LEFT FRONT OF ENGINE COMPT) CDS FUSE ENGINE ROOM R/B 6 (RIGHT FRONT OF ENGINE COMPT, ON RADIATOR SUPPORT) FAN 1 RELAY FUSE FUSE HOLDER (BEHIND LEFT END OF DASH) FUSIBLE LINK BLOCK (TOP LEFT SIDE OF OF ENGINE ROOM J/B) FUSIBLE LINK MAIN (14 GA- GENERATOR GRN WIRE HAZARD FUSE HAZARD SWITCH HEAD RELAY HEADLIGHTS SYSTEM HORN RELAY HTR FUSE HTR RELAY INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH, AT LOWER FINISH PANEL) J/C 14 (BEHIND RIGHT KICK PANEL) J/C 4 (BEHIND UPPER LEFT SIDE OF DASH) J/C 8 (BEHIND LOWER CENTER OF DASH) MAIN FUSE POWER OUTLET POWER OUTLET FUSE POWER OUTLET RELAY (ON DRIVER SIDE J/B) RDI FUSE RED WIRE SHORTING PIN ST RELAY TO CIG FUSE (DIAGRAM 2 OF 2) TO IGNITION SWITCH (DIAGRAM 2 OF 2) TO POWER FUSE (DIAGRAM 2 OF 2) WHT WIRE YEL WIRE

A/C FAN 2 RELAY, ENGINE MAIN RELAY, FAN 1 RELAY ABS ACTUATOR, ECU BLK WIRE BLU WIRE CENTER AIR BAG SENSOR ASSEMBLY CENTER J/B (BEHIND INSTRUMENT CLUSTER) CIG FUSE CIGARETTE LIGHTER CLUTCH START SWITCH, ENGINE CONTROL MODULE, PARK/NEUTRAL POSITION SWITCH, COMBINATION METER CRUISE CONTROL CLUTCH SWITCH, P/W RELAY CRUISE CONTROL ECU D/L FUSE STOP FUSE DATA LINK CONNECTOR 3 DEF FUSE DEF I-UP/ M-HTR FUSE DEF RELAY ECU-B FUSE ECU-IG FUSE EFI OR F-HTR RELAY ENGINE CONTROL MODULE FOG FUSE FROM ALT FUSE (DIAGRAM 1 OF 2) FROM POWER OUTLET RELAY (DIAGRAM 1 OF 2) FRONT WIPER, WASHER SWITCH, FRONT WIPER MOTOR FUSE (DIAGRAM 1 OF 2) GAUGE FUSE GRN WIRE GRY WIRE HAZARD SWITCH IE (ON LEFT DASH BRACE) IGN FUSE IGNITION SWITCH INJECTORS INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH, AT LOWER FINISH PANEL) INTEGRATION RELAY J/C 8 (BEHIND LOWER CENTER OF DASH) LOCK NOISE FILTER (DOME) NOISE FILTER, IGNITION COIL, IGNITERS OBD FUSE ORG/ WIRE P/W RELAY POWER FUSE REAR WINDOW DEFOGGER RED WIRE SHIFT LOCK ECU ST FUSE STOPLIGHT SWITCH TAIL FUSE TAIL RELAY TURN FUSE WIP FUSE WASHER MOTOR WHT WIRE YEL WIRE
