Horn circuit for Toyota Celica T230 (1999-2002)
Horn circuit
BODY ECU (RIGHT SIDE OF CENTER CONSOLE)
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPARTMENT)
GRN WIRE
GRN/YEL WIRE
HORN FUSE
HORN RELAY
HORN SWITCH (PART OF COMBINATION SWITCH)
HOT AT ALL TIMES
LEFT HORN (LEFT FRONT OF ENGINE COMPARTMENT)
LT BLU WIRE
RIGHT HORN (RIGHT FRONT OR ENGINE COMPARTMENT)
W/O DOOR LOCK CONTROL W/ DOOR LOCK CONTROL
YEL WIRE
