Toyota Celica T200 facelift (1995-1999) Courtesy lamps circuit

BLU/YEL WIRE COMBINATION METER COUPE, CONVERTIBLE LIFTBACK DCTY DIODE (BELOW DRIVER'S DOOR SILL, TAPED TO HARNESS) (DOOR COURTESY LIGHT) DIODE (BELOW DRIVER'S DOOR SILL, TAPED TO HARNESS) (LUGGAGE COMPARTMENT LIGHT) DOOR DOOR OFF ON GRN/YEL WIRE HOT AT ALL TIMES R/B 2 (ON LEFT SIDE OF ENGINE COMPARTMENT) DOME FUSE IGNITION KEY CYLINDER LIGHT INTEGRATION RELAY J/B 1 (BEHIND LEFT KICK PANEL) J/B 3 (BEHIND CENTER OF DASH) J/C 1 (UPPER LEFT KICK PANEL) LEFT LEFT DOOR COURTESY LIGHT LEFT DOOR COURTESY SWITCH LEFT PERSONAL LIGHT (W/ CONVERTIBLE) LIFTBACK LUGGAGE COMPARTMENT LIGHT LUGGAGE COMPARTMENT LIGHT SWITCH OPEN DOOR WARNING LIGHT PCTY PERSONAL LIGHT (W/ MOONROOF) PERSONAL LIGHT (W/O MOONROOF) RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT RIGHT DOOR COURTESY LIGHT RIGHT DOOR COURTESY SWITCH RIGHT PERSONAL LIGHT (W/ CONVERTIBLE) W/O MOONROOF W/ MOONROOF WHT/BLK WIRE
