Toyota Celica T200 facelift (1995-1999) 4 7 w/ power windows w/o power windows Wiring diagram
This page shows the only wiring diagram for the component.4 7 w/ power windows w/o power windows, which is found in the car Toyota Celica T200 facelift (1995-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 4 7 w/ power windows w/o power windows (1 of 1)
1 3 W/ POWER WINDOWS W/O POWER WINDOWS
4 7 W/ POWER WINDOWS W/O POWER WINDOWS
BLK WIRE
BRN WIRE
CIG, RAD FUSE
GRN WIRE
GRY WIRE
HOT IN ACC OR ON
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
J/B 1 (LEFT KICK PANEL)
J/B 3 (BEHIND CENTER OF DASH)
LEFT REMOTE CONTROL MIRROR
LT GRN WIRE
LT LT
MV M+
MV MH M+
OPERATION SWITCH
RED WIRE
REMOTE CONTROL MIRROR SWITCH
RIGHT LEFT
RIGHT REMOTE CONTROL MIRROR
RIGHT RIGHT LEFT LEFT
SELECT SWITCH RIGHT LEFT
UP DOWN
W/ POWER WINDOWS
W/ POWER WINDOWS W/O POWER WINDOWS
W/O POWER WINDOWS
WHT WIRE
YEL WIRE
Go to component -> Power mirror circuit -> 4 7 W/ POWER WINDOWS W/O POWER WINDOWS
