Instrument illumination circuit for Toyota Celica T200 (1993-1995)

ASHTRAY ILLUMINATION BLK WIRE BLU WIRE CIGARETTE LIGHTER ILLUMINATION EX FOR SEPARATE TYPE AMPLIFIER FOR SEPARATE TYPE AMPLIFIER GLOVE BOX LIGHT GLOVE BOX LIGHT SWITCH GRN WIRE GRY WIRE HAZARD SWITCH HEATER CONTROL SWITCH HOT AT ALL TIMES ILL+ ILL- ILL+ ILL- INSTRUMENT CLUSTER INTEGRATION RELAY (J/B #1) J/B 1 (LEFT KICK PANEL) J/B 3 (BEHIND CENTER OF I/P) JUNCTION CONNECTOR (LEFT SIDE OF I/P) JUNCTION CONNECTOR (LEFT SIDE OF I/P) (FOR GROUND) LIGHT CONTROL SWITCH COMBINATION SWITCH LT GRN WIRE NOISE FILTER NO. 1 O/D MAIN SWITCH OFF HEAD TAIL PANEL FUSE RADIO AND PLAYER REAR WINDOW DEFOGGER SWITCH RHEOSTAT STEREO COMPONENT AMPLIFIER TAILLIGHT RELAY WHT WIRE WHT/BLK WIRE WHT/GRN WIRE YEL WIRE
