Toyota Celica T200 (1993-1995) right remote control mirror Wiring diagrams
This page contains all the electrical diagrams for the component. right remote control mirror, in which he is found in the car Toyota Celica T200 (1993-1995). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right remote control mirror (1 of 2)
1995 VFTC
BLK WIRE
BRN WIRE
CIG, RAD FUSE
GRY WIRE
HOT IN ACC OR ON
INPANE J/B (LEFT KICK PANEL)
J/B 3 (BEHIND CENTER OF I/P)
LEFT REMOTE CONTROL MIRROR
LEFT UP RIGHT DOWN
LT GRN WIRE
MV M+
MV MH
OPERATION SWITCH
RED WIRE
REMOTE CONTROL MIRROR SWITCH
RIGHT LEFT
RIGHT REMOTE CONTROL MIRROR
SELECT SWITCH
UP DOWN
VR HR
WHT WIRE
YEL WIRE
Go to component -> Power mirror circuit, without power windows -> RIGHT REMOTE CONTROL MIRROR
Wiring diagram right remote control mirror (2 of 2)
1995 VFTC
BLK WIRE
BRN WIRE
CIG, RAD FUSE
GRY WIRE
HOT IN ACC OR ON
INPANE J/B (LEFT KICK PANEL)
J/B 1 (LEFT KICK PANEL)
LEFT REMOTE CONTROL MIRROR
LEFT UP RIGHT DOWN
LT GRN WIRE
MH MV
MV M+
OPERATION SWITCH
RED WIRE
REMOTE CONTROL MIRROR SWITCH
RIGHT LEFT
RIGHT REMOTE CONTROL MIRROR
SELECT SWITCH
UP DOWN
VL 10
VR HR
WHT WIRE
YEL WIRE
Go to component -> Power mirror circuit, with power windows -> RIGHT REMOTE CONTROL MIRROR
