Toyota Celica T200 (1993-1995) hot with light control switch in head or tail position Wiring diagram
This page shows the only wiring diagram for the component.hot with light control switch in head or tail position, which is found in the car Toyota Celica T200 (1993-1995). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot with light control switch in head or tail position (1 of 1)
1995 VFTC
2.2L 1.8L M/T 1.8L A/T
BLK WIRE
BLU WIRE
COUPE (EXCEPT- STANDARD MODEL)
DEF FUSE
DEFOGGER RELAY
DIODE (FOR IDLE-UP)
ELECTRONIC CONTROLLED
ELS
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HOT WITH LIGHT CONTROL SWITCH IN HEAD OR TAIL POSITION
HTR FUSE
IMPANE J/B (LEFT KICK PANEL)
J/B 3 (BEHIND CENTER OF I/P)
J/C 6 (BEHIND RIGHT SIDE OF I/P)
J/C 9
LIFTBACK, COUPE (STANDARD MODEL)
MIR HTR FUSE
NOISE FILTER NO. 2
ORG/ WIRE
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER SWITCH
RED WIRE
RIGHT REAR DOOR
TAIL FUSE
TRANSMISSION ECU (A/T) ENGINE CONTROL MODULE (M/T) (FRONT END OF CENTER CONSOLE)
WHT WIRE
Go to component -> Defogger circuit -> HOT WITH LIGHT CONTROL SWITCH IN HEAD OR TAIL POSITION
