Toyota Celica T200 (1993-1995) from r/b 2 alt and abs fuses Wiring diagram
This page shows the only wiring diagram for the component.from r/b 2 alt and abs fuses, which is found in the car Toyota Celica T200 (1993-1995). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram from r/b 2 alt and abs fuses (1 of 1)
ABS ECU
BLK WIRE
BLU/ YEL WIRE
BLU/YEL WIRE
CRUISE CONTROL ECU
DAYTIME RUNNING LAMP RELAY (CANADA)
DEF FUSE
DEFOGGER RELAY
DIODE (FOR IDLE-UP)
DOME FUSE
DOOR FUSE
DOOR LOCK CONTROL RELAY
ECU (A/T)
ECU-B FUSE
ELS
ENGINE AND ELECTRONIC CONTROLLED TRANSMISSION
ENGINE CONTROL MODULE (M/T)
FROM
FROM J/B 1 HTR FUSE
FROM R/B 2 ALT AND ABS FUSES
GRN RED/ WIRE
GRN WIRE
GRY OR BRN OR BLU/YEL WIRE
INTEGRATION RELAY
J/C 2
J/C 7
LUGGAGE COMPARTMENT LAMP
MIR HTR FUSE
NOISE FILTER 2
OPEN DOOR WARNING LAMP (COMBINATION METER)
ORG OR GRY OR BRN WIRE
ORG/ WIRE
PERSONAL LAMP AND PERSONAL LAMP WITH MOON ROOF CONTROL SWITCH
POWER FUSE
POWER MAIN RELAY
R/B 2
REAR WINDOW DEFOGGER
RED GRN/ WIRE
RIGHT DOOR COURTESY LAMP
TAIL FUSE
TAIL LAMP RELAY
TO J/B 1, PANEL FUSE
WHT WIRE
WHT/BLU WIRE
YEL BLU/ WIRE
Go to component -> Power distribution circuit (3 of 4) -> FROM R/B 2 ALT AND ABS FUSES
