Toyota Camry XV80 (2024-2024) Courtesy lamps circuit

BLK WIRE COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM CTYL CTYR DOME CUT RELAY ECU-IGR 2 FUSE ENGINE ROOM R/B ASSEMBLY 1 FLCL FRCL FSPT GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGR 1 RELAY ENERGIZED HOT W/ IGR 2 RELAY ENERGIZED IGR INP STD 1 FUSE LCTY LEFT FRONT DOOR LOCK W/ MOTOR ASSEMBLY LEFT REAR DOOR LOCK W/ MOTOR ASSEMBLY MAIN BODY ECU METER-IGR FUSE ORG/ WIRE PNK CANH WIRE POWER DISTRIBUTION BOX ASSEMBLY PPL PPL/BLU WIRE PPL/GRY WIRE PPL/PNK WIRE RCTY RED WIRE RIGHT FRONT DOOR LOCK W/ MOTOR ASSEMBLY RIGHT REAR DOOR LOCK W/ MOTOR ASSEMBLY TCYL VIO WIRE WHT WIRE WHT/BLK WIRE

BLK WIRE BLU WIRE BRN WIRE CTY ECU-IGR 4 FUSE ENGINE ROOM R/B ASSEMBLY 1 GRN WIRE GRY WIRE HOT W/ IGR 1 RELAY ENERGIZED LEFT "C" PILLAR) LEFT FRONT COURTESY LIGHT ASSEMBLY LEFT FRONT DOOR INSIDE HANDLE LIGHT (INTERIOR ILLUMINATION LIGHT ASSEMBLY 1) LRLP LT GRN WIRE LUGGAGE COMPARTMENT LIGHT ASSEMBLY 2 PNK WIRE PPL/BLK WIRE PPL/BLU WIRE PPL/BRN WIRE PPL/GRN WIRE PPL/GRY WIRE PPL/LT BLU WIRE PPL/ORG WIRE PPL/PNK WIRE PPL/RED WIRE PPL/WHT WIRE RADIO SETTING CONDENSER RED WIRE RIGHT FRONT COURTESY LIGHT ASSEMBLY RIGHT FRONT DOOR INSIDE HANDLE LIGHT (INTERIOR ILLUMINATION LIGHT ASSEMBLY 1) RIGHT INSTRUMENT PANEL LIGHT (INTERIOR ILLUMINATION LIGHT ASSEMBLY 1) ROOM LIGHT ASSEMBLY SIG TELEMATICS TRANSCEIVER W/ ROOM LIGHT ASSEMBLY W/O ROOM LIGHT ASSEMBLY WHT WIRE

BLK WIRE BLU WIRE BRN WIRE CTY DOOR GRN WIRE GRY WIRE LEFT INSTRUMENT PANEL UNDER COVER LIGHT (INTERIOR ILLUMINATION LIGHT ASSEMBLY 1) LEFT VANITY LIGHT ASSEMBLY LEFT VISOR ASSEMBLY LT BLU WIRE LUGGAGE COMPARTMENT LIGHT ASSEMBLY 1 PNK WIRE PPL PPL/BLK WIRE PPL/GRN WIRE PPL/GRY WIRE PPL/LT BLU WIRE PPL/PNK WIRE PPL/RED WIRE PPL/WHT WIRE RED WIRE RIGHT VANITY LIGHT ASSEMBLY RIGHT VISOR ASSEMBLY RLMP ROOF CONSOLE BOX SUB-ASSEMBLY RRID SPOT LIGHT ASSEMBLY VIO WIRE W/ SLIDING ROOF, PANORAMIC MOON ROOF SYSTEM W/O SLIDING ROOF, PANORAMIC MOON ROOF SYSTEM
