Toyota Camry XV50 facelift 2 (2017-2018) Battery cooling fan circuit, hybrid

Battery cooling fan circuit, hybrid

Car Wiring Diagrams for Camry Toyota XV50 facelift 2 (2017-2018): Battery cooling fan circuit, hybrid

BATT FAN FUSE BATTERY COOLING BLOWER ASSEMBLY BATTERY VOLTAGE SENSOR BLK WIRE BLU WIRE HOT W/ IGCT RELAY ENERGIZED HV SUPPLY BATTERY ASSEMBLY HYBRID VEHICLE CONTROL ECU ASSEMBLY LT GRN WIRE PNK WIRE R/B 4 RED WIRE VIO WIRE W/ LITHIUM-ION BATTERY W/ NICKEL METAL HYDRIDE BATTERY WHT/BLK WIRE
