Starting circuit, w/o smart key system for Toyota Camry XV50 (2011-2014)
Starting circuit, w/o smart key system
3.5L, 2.5L
ALT FUSE
BATTERY
BLK WIRE
BLU WIRE
CAN L
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL MODULE (ECM)
ENGINE ROOM J/B
ENGINE ROOM R/B
GRN WIRE
IGNITION OR STARTER SWITCH ASSEMBLY
INSTRUMENT PANEL J/B
LOCK
LT GRN WIRE
MAIN FUSIBLE LINK
ON OFF
PARK/NEUTRAL POSITION SWITCH ASSEMBLY
PNK WIRE
RED WIRE
ST RELAY
STARTER
WHT WIRE
WHT/BLK WIRE
YEL WIRE
