Steering lock circuit, except hybrid for Toyota Camry XV50 (2011-2014)
Steering lock circuit, except hybrid
1 2 3 4 5 6 7 GND
17 14 15 LIN CANH CANL COMPUTER DATA LINES SYSTEM
3 2 1 PNK PNK PNK WIRE
BLK WIRE
BLU WIRE
CERTIFICATION ECU (RIGHT SIDE OF DASH)
ENGINE
ENGINE ROOM J/B (LEFT SIDE OF ENGINE COMPT)
FUSE
HOT AT ALL TIMES STRG ROOM R/B LOCK (LEFT SIDE FUSE OF ENGINE COMPT)
HOT IN ON OR START
IGE PNK WIRE
LIN
LT BLU WIRE
LT GRN WIRE
PNK SLP WIRE
PNK WIRE
REMOTE ENGINE STARTER (BEHIND CENTER OF DASH)
RSLP
SL/R
STEERING LOCK ACTUATOR ASSEMBLY (LEFT SIDE OF DASH)
VIO WIRE
W/ REMOTE ENGINE STARTER SYSTEM W/O REMOTE ENGINE STARTER SYSTEM
WHT WIRE
WHT/BLK WIRE
