Shift interlock circuit, hybrid for Toyota Camry XV50 (2011-2014)
Shift interlock circuit, hybrid
BLU WIRE
COMPUTER DATA LINES SYSTEM
DETECTION
ENGINE ROOM R/B 2 (RIGHT SIDE OF ENGINE COMPT)
FUSE
GRN WIRE
HOT AT ALL TIMES INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) STOP FUSE
HOT IN ON OR START
HOT W/ IGCT RELAY ENERGIZED
LT BLU WIRE
PM IGCT FUSE
PNK WIRE
POWER MANAGEMENT CONTROL ECU (LEFT SIDE OF DASH)
RED WIRE
SHIFT LEVER POSITION SENSOR (FRONT OF ENGINE COMPT)
SHIFT LOCK CONTROL ECU (UNDER CENTER FLOOR CONSOLE)
SHIFT LOCK SOLENOID
SLS+
STOP LIGHT SWITCH ASSEMBLY
STP IG
WHT WIRE
WHT/BLK WIRE
YEL WIRE
