Power top/sunroof circuit for Toyota Camry XV50 (2011-2014)
Power top/sunroof circuit
1 2 3 4 5 6 7 8 9 10 11 12 IG
14 13 CANH CANL
4 2 5 3 1 DOWN CLS UP OPN GND
ALTB IG
BLK WIRE
BLU WIRE
BRN WIRE
BUZZER
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY DRIVER
ECU-ACC FUSE
ECU-B 1 FUSE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACC 1 RELAY ENERGIZED
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY
MAIN BODY ECU
PNK WIRE
RED WIRE
RELAY ENERGIZED
ROOF CONSOLE BOX ASSEMBLY
S/ROOF FUSE
SLIDING ROOF CONTROL SWITCH
UP CLS DWN OPN
VIO WIRE
WHT WIRE
WHT/BLK WIRE
