Power mirrors circuit for Toyota Camry XV50 (2011-2014)
Power mirrors circuit
BLK WIRE
BLU WIRE
CONTROL CIRCUIT
DEFOGGER SYSTEM
ECU-ACC FUSE
FOLD
GRN WIRE
GRY WIRE
HOT IN ACC OR ON
HR+ HR-
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LEFT OUTER REAR VIEW MIRROR ASSEMBLY
LT GRN WIRE
MH MV
MIRROR HEATER
MLH
MLV MRV
MR HL+ HL- M+
MR M+
MRH
OPERATION SWITCH
OUTER MIRROR SWITCH ASSEMBLY
RED WIRE
RETRACT SWITCH
RIGHT DOWN LEFT UP
RIGHT LEFT
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY
SELECT SWITCH
UNFOLD
UP DOWN
VIO WIRE
W/ RETRACTOR MIRROR
W/O RETRACTOR MIRROR
WHT WIRE
WHT/BLK WIRE
